Cylinder Information
| Cylinder Size |
Diameter x Length | Tare weight | Internal Volume | Pressure Rating | ||||
|---|---|---|---|---|---|---|---|---|
| Inches | Cm | Lbs | Kg | Cu. Ft | Liters | Psig | Bar | |
| Steel Cylinders | ||||||||
| 1 | 9 x 55 | 23 x 140 | 136.0 | 62.0 | 1.72 | 49.0 | 2400 | 166.5 |
| 2 | 9. x 51 | 23 x 130 | 115.0 | 52.0 | 1.55 | 44.0 | 2265 | 157.2 |
| 3 | 7 x 32 | 18 x 81 | 47.0 | 21.0 | 0.56 | 16.0 | 2015 | 139.9 |
| 4 | 7 x 18 | 18 x 46 | 22.0 | 10.0 | 0.28 | 8.0 | 2015 | 139.9 |
| 5 | 4 x 16 | 10 x 41 | 11.0 | 5.0 | 0.11 | 3.0 | 2015 | 139.9 |
| Lecture Bottle | 2 x 12 | 5 x 30 | 2.3 | 1.0 | 0.01 | 0.42 | 1800 | 125.1 |
| Aluminum Cylinders | ||||||||
| 2A | 8 x 47.5 | 20.0 x 121.0 | 50.0 | 23.0 | 1.06 | 30.0 | 2015 | 139.9 |
| 3A | 7.2 x 35.0 | 18.4 x 88.9 | 33.0 | 15.0 | 0.55 | 15.7 | 2216 | 153.8 |
| 4A | 7.0 x 16.0 | 18.0 x 41.0 | 15.0 | 7.0 | 0.25 | 7.0 | 2015 | 139.9 |
| 6A | 3.2 x 9.4 | 80.0 x 24.0 | 1.5 | 0.7 | 0.03 | 0.9 | 1800 | 125.1 |
| European Cylinders | ||||||||
| E-10 | 5.5 x 33 | 14 x 84 | 33.0 | 15.0 | 0.35 | 10.0 | 2900 | 201.0 |
| E-20 | 8.0 x 33 | 20 x 84 | 39.0 | 18.0 | 0.71 | 20.0 | 2900 | 201.0 |
| E-50 | 9.3 x 59 | 24 x 150 | 137.0 | 62.0 | 1.77 | 50.0 | 2900 | 201.0 |
| G-10 | 5.5 x 33 | 14 x 84 | 26.0 | 12.0 | 0.35 | 10.0 | 2175 | 151.0 |
| G-50 | 9.3 x 59 | 24 x 150 | 129.0 | 59.0 | 1.77 | 50.0 | 2175 | 151.0 |
| Non-Refillable Cylinders | ||||||||
| D-1 | 4 x 20.5 | 10 x 52 | 12.0 | 5.0 | 0.13 | 3.7 | 2200 | 152.7 |
| D-2 | 4 x 14.0 | 10 x 36 | 8.0 | 4.0 | 0.08 | 2.4 | 2200 | 152.7 |
| D-3 | 4 x 07.5 | 10 x 19 | 5.0 | 2.0 | 0.04 | 1.0 | 2200 | 152.7 |
| D-7 | 3 x 12.0 | 8 x 30 | 2.0 | 1.0 | 0.04 | 1.1 | 0240 | 17.5 |
